Description
FULL TITANIUM MUFFLER SPECIFICATION
| TOMEI | OEM | ||
| TYPE-R | TYPE-D | ||
| PART No. | TB6090-SB06A | TB6090-SB06B | - |
| MATERIAL | TITANIUM | - | |
| MAIN PIPE DIAMETER | 3.2inch [80.5mm ] |
3.2inch [80.5mm ] |
2.4 inch [60.0mm] |
| MAIN PIPE THICKNESS | 1.0mm | - | |
| SUB SILENCER DIAMETER | 4.7inch [118.0mm] |
4.7inch x 2 [118.0mm x 2] |
19.0*8.7*4.3inch [480*220*110 mm] |
| SUB SILENCER THICKNESS | 1.0mm | - | |
| SILENCER DIAMETER | 6.0inch [152.0mm] |
6.0inch x 2 [152.0mm x 2] |
(14.0*12.0*90inch) x 2 [(350*300*230 mm) x 2] |
| SILENCER THICKNESS | 1.0mm | - | |
| EXIT DIAMETER | 4.5inch [115.0mm)] |
4.5inch x 2 [115.0mm x 2] |
3.1inch x 4 [80.0mm] x 4 |
| EXIT THICKNESS | 1.0mm | - | |
| FLANGE THICKNESS | 8.0mm | - | |
| WEIGHT | 17.9lbs [8.1kg] |
26.5lbs [12.0kg] |
48.1lbs [21.8kg] |
